Explore STAGEV WALLBOX
Choose the charger that fits your needs. The CORE model is a solid base with basic features, PRO offers advanced management options, and INTELLI provides smart solutions for the most demanding users.
Features STAGEV Wallbox
| Max. charging power | 22 kW |
| Connector | 1 or 3 phase with protective conductor |
| Support for vehicle connector type | Type 1, Type 2 or Chinese equivalents |
| Measurement of energy consumed (without certificate) | in each charger |
| Possibility of using a certified energy meter: | necessary to account for energy consumption |
| Hermetic housing | IP 65 |
| Wall or pole mounting | also in duo system |
| Charger cable wound on the back of the case | including a socket for the charging connector |
| Built-in anti-theft system | GHz radar + buzzer |
| Very easy installation | possible by any electrician |
| Versatile housing | for different hardware solutions |
| Executive components | premium |
| Recharge activation | PIN, application or button - depending on the type |
| Tempered glass touch panel | with any color and functionality |
| With TFT display | either without |
| Communications | WIFI, LTE (2G, 3G & 4G) |
| Dedicated mobile application | Yes |
| Charger ready to work with telemetry system | Yes |
| Compliance with standards | IEC 61851-1, IEC 61851-21-2, CE EMC EU/2014/30, CE EMC EU/2014/35, RED EU/2014/53 |
EXPLORE VARIANTS of WALLBOX STAGEV
The STAGEV charger will fit your needs – choose from a variety of variants with different power, functions and mounting options.
MODERN AND VERSATILE STAGEV WALLBOX Charger
The STAGEV charger is an advanced device dedicated to electric vehicle charging, featuring high power, modern connectivity and comprehensive management functions.
STAGEV WALLBOX is a device tailored to the needs of both individual and fleet users, offering advanced charging functions, wide compatibility and convenience of use. Thanks to modern technologies and integration with management systems, the charger is a reliable solution for electromobility.
1. Ecology and economy
- Optimize charging for photovoltaics: Take advantage of solar energy, minimizing charging costs and environmental impact.
- Efficient phase management: Automatically adjust the load to the available power to avoid overloading the grid.
- Low standby power consumption: Charger designed to save energy even when not active.
- Interoperability with smart energy systems: Can be integrated with home energy management systems (smart home).
- Long life: Robust design and state-of-the-art safety features ensure reliable operation for many years.
2. Connectivity and integration
- Wireless connectivity: Wi-Fi, LTE (2G, 3G, 4G), GSM (SIM card).
- Wired connectivity: Ethernet, RS 485.
- Smart home solutions: LoRaWAN – compatibility with smart home systems.
- Integration with management systems: Possibility to work with customer systems, e.g. in public or corporate spaces.
- Integration with MME: MME-ready device with manufacturer’s applications for easy charge management.
3. Features and security
-
- Device authentication: Ability to secure access via PIN, NFC, app or RFID.
- LCD display: Shows real-time charging status, energy consumption, charging time and cost.
- MID meter: Accurate energy measurements that comply with European standards.
- Blackout protection: Guarantees stable charging even in the event of power outages.
- Charge optimization:
- In terms of photovoltaics – maximum utilization of solar energy.
- In terms of phases – efficient management of power consumption.
4. Comfort of use
- Mobile app: Free app available for individual users, fleet managers and installers. Allows full control and monitoring of charging.
- Cable: Standard 5 meters, optional 7 meters for installation flexibility.
- Compact dimensions: 39 cm x 23 cm x 12.5 cm and low weight of 2.5 kg – easy to install in various locations.
5. Charging power and communication standards
- Charging power: up to 22 kW – fast and efficient charging of electric cars.
- Supported protocols: OCPP 1.6, as well as OCPP 2.0.1 (feature available in late 2025), enabling integration with charging station management systems.
6. Compatibility and integration
- Ability to integrate with the customer’s charging station management system.
- Cooperation with manufacturer’s applications (MME).
- Support for smart energy systems (smart home).
WALL BOX AC SA device
The STAGEV charger combines modern technology, safety, and efficiency. It is ideal for both individual users and companies looking for reliable solutions to power their electric vehicles.
DEVICE Wallbox
AC SA is a Polish company with over 30 years of experience, whose products are sold to customers all over the world. Our power supply technologies are present in over 50 countries on 6 continents. Join the 5 million users of our technologies from around the world.
0
countries
0
continents
0
million cars
Install app!
Gain full control over the charging of your electric vehicle! With the STAGEV app, you can remotely manage your charger, monitor energy consumption and optimize costs. Easy to use, available on Android and iOS – install now and enjoy the full possibilities.
Contact us!
Do you have questions about the STAGEV Wallbox? We’d be happy to answer
Robert Rudnicki
Director of Business Development and Sales in E-mobility/STAGEV
MORE about wallbox
Explore the advanced capabilities of our wallbox chargers – from flexible charging modes, to remote app management, to full compatibility with photovoltaic systems. Discover technology that combines convenience, safety and savings.
